$23,999.00
Ships in 2–4 WeeksSKU: GLG-SPD-ZZKD-SSW8L304S
Free shipping on orders over $500
Made-to-order: ships in 2–4 weeks
| Air Inlet Temperature | Room temperature-350°C |
| Air Outlet Temperature | Room temperature was at-120°C |
| Evaporation Rate | Max 8000m3/h |
| Heat Source | Electric |
| Temperature Adjustment Accuracy | ±1°C |
| Drying Air Volume | MAX 340m /h frequency regulation boost |
| Fogging Motor | MAX 42000rpm frequency regulation speed |
| Atomizing Disk | Stainless Steel 55mm |
| Control System | Embedded intelligent control system for spray drying |
| Inlet Air Temperature Adjustment | PID digital real-time group ring temperature adjustment |
| Touch Screen | Temperature, air speed, feeding, cleaning and other |
| Heater | 18kW double channel |
| Feeding | Peristaltic pump MAX15L/h |
| Tower Wall Vibration | Air hammer vibration |
| Fan | 3.2kW |
| Observation Room | Semi-automatic quick opening door |
| Drying Chamber | Inner φ1000mm |
| Overall Dimensions | L×W×H (mm) 1250 × 1350 × 2150 |
| Material | SS304 |
| Weight | 450.0 kg |
| Power Supply | 240V/380V three-phase |
| Overall Power | 22.0 kW |
