| Reactor Type | Stirred Reactor |
| Reaction Capacity | 10L |
| Inner Diameter | 230mm |
| Outer Diameter | 290mm |
| Inner Length | 354mm |
| Mezzanine Capacity | about 8L |
| Voltage Frequency | 110V/60HZ（220V optional） |
| Machine Power | 0.13 kW |
| Stirring Motor Power | 90W (1/3) |
| Lifting Motor Power | 40W (1/12.5) |
| Stirring Speed | 0-450rpm/min |
| Temperature Range Of Kettle Body | -80°C~ +250°C |
| Temperature Measurement Accuracy | ±1°C |
| Vacuum Degree |
| 0.098Mpa |
| Stirring Paddle | Φ17×700H, Blade diameter: 150 |
| Condenser | Φ100×600H(mm) Bottom 60Flange |
| Condensation Area | 0.4㎡ |
| Lifting Stroke Of The Main Machine | 500mm |
| Rotation Of The Reaction Body | 150° to the left |
| Packing Size | 1870×600×1020mm |
| Packing Weight | 170.0 kg |
| Other Capacitymodel | can be customized |
