1 / 22The Swiben DC-2010 is a benchtop heating and cooling circulator that combines refrigeration and heating in a single 10L bath. It operates across a temperature range of -20°C to 100°C with a temperature stability of ±0.05°C and resolution of 0.01°C, making it suited to constant-temperature work.
The unit uses a 304 stainless steel tank and work surface with a PT100 temperature sensor and PID control through an LCD instrument. Internal and external circulation modes allow the bath to serve as a standalone temperature-controlled reservoir or to supply fluid to connected equipment such as jacketed vessels.
It is intended for laboratory and process settings that require controlled heating or cooling of samples, reactions, or external apparatus.
The circulator regulates bath fluid temperature using a refrigeration system and a 600 W heater, with a PT100 sensor feeding a PID controller for closed-loop control. A built-in pump moves fluid in internal circulation within the tank or external circulation to connected equipment, delivering up to 8 L/min at a pump head of 4.59 ft.
Model: DC-2010
Swiben DC-2010 refrigerated heating and cooling circulator with a 10L stainless steel tank, -20°C to 100°C range, and internal/external circulation.
This equipment is sold for lawful use only. Buyer is responsible for compliance with all applicable regulations.
