1 / 20The Swiben DC-2006 is a refrigerated recirculating chiller and heating circulator built around a 6 L stainless steel tank. It operates across a temperature range of -20°C to 99°C with a stated temperature stability of ±0.05°C and a control resolution of 0.01°C, making it suitable for applications that require a controlled, constant-temperature bath.
The unit supports both internal and external circulation, allowing it to serve as a constant-temperature bath on its own or to supply heated or cooled fluid to connected equipment such as jacketed vessels. The circulation pump delivers a flow rate of 8 L/min with a pump head of roughly 4.59 ft.
With a 304 stainless steel work surface and tank, an LCD control instrument, and a compact 25 kg footprint, the DC-2006 is intended for laboratory and processing environments that need repeatable low-temperature and heating control.
Working fluid is held in the 6 L tank and conditioned by the refrigeration circuit and a 600 W heating element to reach the set temperature. A PT100 sensor feeds a PID control loop, which can be auto-tuned or adjusted manually, to hold the bath within ±0.05°C. The circulation pump moves fluid internally within the tank or externally to connected equipment at up to 8 L/min.
Model: DC-2006
Refrigerated heating/cooling circulator with a 6L stainless tank, -20°C to 99°C range, and ±0.05°C stability for lab temperature control.
This equipment is sold for lawful use only. Buyer is responsible for compliance with all applicable regulations.
