1 / 26The ZZKD GYY-5L is a heated circulating bath that can operate as a water bath up to 99°C or as an oil bath up to 200°C. It uses an immersed electric heating tube and PID temperature control with a digital display for setting and monitoring temperature.
The 5L stainless steel tank is fitted with a full stainless steel magnetic circulating pump that moves heat-transfer fluid at 15–20 L/min, supporting external circulation to connected glassware. Insulation between the shell and liner helps maintain temperature stability.
This unit is intended for laboratory tasks such as drying, concentration, and distillation, and suits research, education, and process settings that require controlled-temperature circulation. It runs on 110V and draws up to 10A.
An immersed heating tube warms the bath fluid while a PID controller regulates the set temperature, displayed digitally. A stainless steel magnetic pump circulates the heated water or oil through the system at 15–20 L/min, allowing the bath to supply controlled-temperature fluid to external equipment.
Model: GYY-5L
5L heated circulating water/oil bath with PID control, 2000W heating, and a stainless magnetic circulating pump. Oil bath reaches up to 200°C.
This equipment is sold for lawful use only. Buyer is responsible for compliance with all applicable regulations.
